Gigabyte X870E Aorus Master AM5 DDR5 Motherboard
The Gigabyte X870E AORUS Master is a flagship AM5 motherboard designed for extreme performance, next-gen connectivity, and premium build quality. Supporting Ryzen 9000, 8000, and 7000 series processors, it delivers cutting-edge features including PCIe 5.0, DDR5 overclocking, and ultra-fast networking.
- Supports AMD Ryzen 9000 / 8000 / 7000 Series processors
- DDR5 memory up to 8600MT/s (OC)
- 4 × M.2 slots including PCIe 5.0 support
- Wi-Fi 7 and 5GbE LAN connectivity
- Dual USB4 Type-C ports
₹58,948.00
Gigabyte X870E AORUS Master AM5 DDR5 Motherboard
AM5 • X870E • DDR5 • PCIe 5.0 • Wi-Fi 7 • 5GbE LAN • ATX
Overview
The Gigabyte X870E AORUS Master is a flagship AM5 motherboard designed for extreme performance, next-gen connectivity, and premium build quality. Supporting Ryzen 9000, 8000, and 7000 series processors, it delivers cutting-edge features including PCIe 5.0, DDR5 overclocking, and ultra-fast networking.
- Supports AMD Ryzen 9000 / 8000 / 7000 Series processors
- DDR5 memory up to 8600MT/s (OC)
- 4 × M.2 slots including PCIe 5.0 support
- Wi-Fi 7 and 5GbE LAN connectivity
- Dual USB4 Type-C ports
Performance & Power
- Digital twin 16+2+2 phase VRM design
- Stable and efficient power delivery for high-end CPUs
- Real-time power monitoring support
Memory Support
| Memory Type | DDR5 |
|---|---|
| DIMM Slots | 4 |
| Max Capacity | 256GB |
| Max Speed | Up to 8600MT/s (OC) |
| Architecture | Dual Channel |
| Support | AMD EXPO & Intel XMP |
Expansion Slots
- 1 × PCIe 5.0 x16 slot (reinforced)
- 2 × PCIe x16 slots (x4 mode)
Storage
- 4 × M.2 slots (3 × PCIe 5.0 + 1 × PCIe 4.0)
- 4 × SATA 6Gb/s ports
- RAID support (0/1/5/10)
Graphics Support
- HDMI output support
- USB4 Type-C with DisplayPort output
- Supports integrated Radeon graphics (CPU dependent)
Networking
- Realtek 5GbE LAN
- Wi-Fi 7 with ultra-high gain antenna
- Bluetooth 5.3
Connectivity
- 2 × USB4 Type-C ports
- USB 3.2 Gen 2 and Gen 1 ports
- Multiple USB 2.0 ports
- Front USB Type-C header (Gen 2×2)
Cooling & Thermal Design
- Advanced VRM Thermal Armor with I/O zone cooling
- M.2 Thermal Guard XL
- Multiple fan and pump headers
- Temperature sensors and noise detection
Build & Convenience
- EZ-Latch Plus for PCIe and M.2 (tool-less installation)
- Q-Flash Plus for BIOS update without CPU
- Sensor Panel Link for in-case display integration
- GIGABYTE Control Center (GCC) support
Audio
- Realtek ALC1220 High Definition Audio
- DTS:X Ultra support
- Audiophile-grade capacitors
- S/PDIF optical output
Internal I/O
- 1 × 24-pin ATX power connector
- 2 × 8-pin CPU power connectors
- Multiple fan and pump headers
- RGB and ARGB Gen2 headers
- USB headers and front panel connectors
Back Panel I/O
- 2 × USB4 Type-C ports
- USB 3.2 Gen 2 Type-A ports
- USB 3.2 Gen 1 ports
- USB 2.0 ports
- RJ-45 LAN port
- Wi-Fi antenna connectors
- Optical S/PDIF and audio jacks
- Q-Flash Plus and Clear CMOS buttons
Operating System
- Windows 11 64-bit
Form Factor
- ATX (30.5cm × 24.4cm)
Warranty
3 Years Manufacturer Warranty
Note: Specifications and features are subject to change without notice.
